Automated Control Wiped Film Distillation Machine For High Purity APIs Nutraceuticals
| Brand Name: | Echo |
| Model Number: | Echo |
| MOQ: | 1 Set |
| Price: | Contact Us for Pricing |
| Payment Terms: | T/T |
| Supply Ability: | 50+ Sets per Month |
Automated Control Wiped Film Distillation Machine
,high efficiency Wiped Film Distillation Machine
,Automated Control Wiped Film Distillation System
This turnkey Purification System integrates advanced Wiped Film Distillation technology within a fully cGMP-compliant framework, purpose-built for the concentration and purification of high-value Active Pharmaceutical Ingredients (APIs) and nutraceutical lipids. Designed as a continuous, closed-loop solution, it ensures the gentle separation of heat-sensitive biomolecules like Omega-3 fatty acids and natural vitamins from complex crude feedstocks. The system provides a complete, skidded unit comprising precision thin-film evaporation, high-vacuum generation, internal condensation, and automated controls. For manufacturers seeking to consistently achieve pharmacopeia-grade purity, eliminate thermal degradation, and scale seamlessly from pilot to production, this purification platform delivers unmatched product integrity, batch-to-batch consistency, and documented compliance with 21 CFR Part 11 and EU GMP Annex 11 requirements.
Pharmaceutical and nutraceutical manufacturers consistently face a critical bottleneck when purifying thermally labile compounds. Traditional purification methods, including batch pot distillation and packed column fractionation, subject valuable APIs to prolonged heat exposure, which leads to the formation of degradation impurities, trans-isomers, and colored by-products. These batch processes also struggle with poor reproducibility and create a significant documentation burden in a GMP environment. The inability to precisely control extended residence times results in product loss, failed quality specifications, and costly rework. As regulatory scrutiny intensifies, continuing to rely on these outdated purification methods directly risks batch rejection and prevents companies from achieving the ultra-high purity levels, such as 90%+ EPA/DHA concentrates, that define premium pharmaceutical ingredient markets.
Our Purification System solves these challenges by replacing a batch still with a continuous, mechanically-driven Wiped Film Evaporator core. This technology instantly spreads the process fluid into a thin, turbulent film under high vacuum, enabling sub-minute residence time evaporation. The result is a purification process that preserves the native molecular structure of your API, preventing the formation of pharmacopeia-limited impurities. The complete system is delivered on a validated skid with all product-contact surfaces electropolished to Ra ≤ 0.5 μm, full material traceability, and an integrated CIP system. A 21 CFR Part 11-compliant PLC with audit trail and user access management controls every parameter, transforming a complex chemical engineering challenge into a documented, repeatable, and regulator-ready unit operation that guarantees the purity of every drop.
| Parameter | Specification |
|---|---|
| System Series | PS-Pharma (Purification System, Pharma Grade) |
| Core Technology | High-Vacuum Wiped Film & Short Path Distillation |
| Product-Contact Material | SS316L, full electropolish, Ra ≤ 0.5 μm |
| Compliance Design | cGMP, 21 CFR Part 11, EU GMP Annex 11 ready |
| Operating Vacuum | 0.001 mbar absolute |
| Residence Time | < 60 seconds |
| Cleaning System | Fully integrated automated Clean-in-Place (CIP) |
| Control Architecture | Siemen or AllenBradley PLC with HMI, audit trail |
| Documentation Package | Full DQ/IQ/OQ support, material certificates, pressure test reports |
| Scalable Capacities | From 1 kg/h (lab/pilot) to 500 kg/h (commercial) |
-
Pharmaceutical: Continuous distillation of Omega-3 ethyl esters to >90% purity meeting USP/EP monographs.
-
Biopharma: Gentle concentration of natural Vitamin E (tocopherols) and beta-carotene from deodorizer distillates.
-
Injectable Grade Excipients: Ultra-purification of parenteral-grade oils, removing pyrogens and oxidative impurities.
-
High-Value APIs: Separation of thermally sensitive prostaglandins, intermediates, and alkaloids.
The process begins with a precisely metered feed entering the degassing stage of the wiped film evaporator. Inside the heated, vacuum-sealed cylinder, a high-speed precision rotor with floating wipers instantly creates a uniformly thin film on the internal wall. The ultra-high vacuum drastically reduces the boiling point, causing the valuable light fraction (API) to evaporate within seconds. This vapor traverses a short, unimpeded path to a central internal condenser and is immediately collected as a pure distillate, while the heavy, non-distillable impurities flow continuously out the bottom residue port. This true continuous operation eliminates start-stop batch variability entirely.
Start by defining your target distillate purity and critical quality attributes (CQAs). A pilot-scale trial in our GMP-simulated lab is the definitive first step for mapping your exact evaporation rate (kg/m²/hr) and required vacuum. Select a system size based on linear scale-up from this pilot data; our engineering team will guarantee the production unit matches the pilot's performance. Crucially, you must specify whether your distillate solidifies at room temperature, as this dictates the need for a precisely controlled “hot condenser” to prevent blockages. Ensure your quotation includes a full traceability and documentation package, a corrosion-resistant vacuum pump set suitable for your solvents, and a heated residue discharge pump for viscous wastes.
-
Q: How does this system help us pass an FDA audit?
A: The system is built with a full, auditable qualification lifecycle. We provide material certificates, weld logs, and surface finish reports. The PLC enforces strict user access levels and records every process alarm and parameter change with a non-editable audit trail, providing the data integrity inspectors require. -
Q: What is the yield advantage over a standard batch pot still?
A: Our continuous purification system typically rec overs 2-5% more high-value distillate. This is due to the elimination of a stagnant, overheated liquid pool, which in batch processes leads to decomposition and mechanical losses during inter-batch cleaning. -
Q: Can a single system purify different APIs without cross-contamination risk?
A: Yes. The design’s extremely low internal hold-up volume (<2% of hourly throughput) and fully automated CIP circuit allow for complete cleaning and a certificate-ready dry surface in hours, enabling validated multi-product campaigns. -
Q: How is the vacuum integrity validated?
A: The system is helium-leak tested at the factory to a defined leak rate. We provide an on-site vacuum integrity test protocol as part of IQ/OQ, ensuring the system can consistently hold the 0.001 mbar operational vacuum required for your process. -
Q: What ongoing support is offered for GMP compliance?
A: Beyond commissioning, we offer annual preventative maintenance, re-qualification services, and a five-year guarantee on critical electropolished vessel integrity. Our application engineers remain on call to support deviation investigations throughout the asset’s lifecycle.
